CO2 Laser Marking Machine/Laser Marking Machine/Marking Machine
- Product Item : AT-61025
- Category： Laser Processing Equipment
- Product description：
Performance Characteristics of CO2 Laser Marking Machine:
The CO2 laser marking machine is a gas laser that uses CO2 as the working substance, offering a long service life and low energy consumption.
The marking software is highly functional, compatible with files from software such as Coreldraw, AutoCAD, and Photoshop. It supports formats like PLT, PCX, DXF, and BMP, and can directly utilize SHX and TTF font libraries. The software supports automatic encoding, printing of serial numbers, batch numbers, dates, barcodes, QR codes, and automatic number skipping.
Applicable Industries for CO2 Laser Marking Machine:
Applicable industries: clothing, leather, craft gifts, wood and bamboo products, advertising and decoration, instrumentation and electronics, daily necessities, model making, food packaging, electronic components, pharmaceutical packaging, etc.
Applicable industries: acrylic, (organic) glass, bamboo and wood products, resin, plastic, paper, cloth, leather, and other non-metallic materials.
Product Parameters:
|
Average Output Power |
10W, 30W, 50W, 100W |
|
Laser Wavelength |
10.6um |
|
Power Adjustment Range |
0-100% |
|
Repetition Frequency |
200-5 0KHZ |
|
Output Beam Quality |
M2<4 |
|
Marking Depth |
0.1-0.3mm |
|
Minimum Focusing Spot |
0.015mm |
|
Minimum Character Height |
0.15mm |
|
Repeatability Accuracy |
±0.003mm |
|
Maximum Linear Marking Speed |
7000mm/s |
|
Standard Engraving Area |
100mmx100mm |
|
Optional Engraving Areas |
80mm², 110mm², 160mm² |
|
Control Interface |
USB |
|
Galvanometer |
High-performance scanning galvanometer |
|
Overall Power Consumption |
1.5KW |
|
Power Requirements |
220V±22V/50Hz/ 12A |
|
Cooling Method |
High-precision constant temperature/closed-loop air cooling |
|
Appearance Dimensions |
600x800mmx1200mm |
|
Weight |
75 KG |
